Overview of flexible lifting belts：
Flexible lifting belts are used to cooperate with lifting hooks and other lifting objects, and can be suitable for lifting objects under various lifting conditions. They have high strength and can not harm the surface of the object. They are lightweight and flexible, and can be used in various combinations.
The outer surface of the flexible lifting belt is fine and will not cause damage to vulnerable objects. Moreover, there are many lifting methods, which can also be used to drag the lifted object. We have sufficient supply of lifting belts and provide various imported lifting belts. It is equipped with a unique label and uses international standard colors to distinguish the bearing tonnage, making it easy to identify even if the lifting belt is worn.
REQUEST A QUOTEDESCRIPTION
Main technical data of flexible lifting belt:
1. Standards: International standard ISO4748, European standard EN1492-2, partial standard JB/T8521;
2. Comply with CE and GS safety requirements;
3. Material: high-strength polyester (PES), nylon;
4. Safety factor: 6:1 or 8:1;
5. Scope: Color code or other requirements;
6. Elongation:<2% - 5% under ultimate working force;
7. Length: according to customer requirements;
8. Working load: 0.5T-1000T (special specifications can be customized).
Main technical data of flat lifting belt:
1. Standards: International standard ISO4748, European standard EN1492-1;
2. Material: high-strength polyester (PES), nylon;
3. Safety factor: 6:1 or 8:1;
4. Scope: Color code or other requirements;
5. Elongation:<2% - 5% under ultimate working force;
6. Length: according to customer requirements;
7. Type: Single layer, double layer, three layer, four layer (special specifications can be customized).
一、 Overview of flexible lifting belts
Flexible lifting belts are used to cooperate with lifting hooks and other lifting objects, and can be suitable for lifting objects under various lifting conditions. They have high strength and can not harm the surface of the object. They are lightweight and flexible, and can be used in various combinations.
The outer surface of the flexible lifting belt is fine and will not cause damage to vulnerable objects. Moreover, there are many lifting methods, which can also be used to drag the lifted object. We have sufficient supply of lifting belts and provide various imported lifting belts. It is equipped with a unique label and uses international standard colors to distinguish the bearing tonnage, making it easy to identify even if the lifting belt is worn.
二、 Technical data for flexible lifting belts
Material: imported DuPont silk, polyester (polyester), nylon, Dinima
Safe working force: 0.5-500T
Effective length: 0.5-80M
Safety factor: 6:1
Range: - 40 ℃ - 10 180 ℃
Elongation: Ultimate working elongation<2% Elongation at break<12%
Executive standard: JB/T8521-2007
三、 Advantages of flexible lifting belts
1. Suitable for lifting circular and annular objects
2. High strength and weight
3. There are many lifting methods for flexible lifting belts and the lifting belts are evenly stressed, resulting in a longer working life of the lifting belts
4. There are many lifting methods, which can also be used to drag the lifted object
5. Additional anti wear and anti cutting protective sleeves are available
6. Non conductive, no danger of electric shock
7. The flexible packaging loop back sling is made of 100% PES, and the inner bearing core is surrounded by a stepless loop to form a circular 100% PES woven into a stress free sleeve to protect the bearing core.
8. Especially suitable for lifting circular and annular objects.
9. The outer surface of the flexible lifting belt is fine, smooth objects will not cause damage, and vulnerable objects will not be damaged
10. Lightweight and soft, easy to use in small spaces.
11. Load 0.5-500 tons, effective length 0.5-80 meters
12. Comply with Chinese industry standard JB/T8521-2007
13. The elastic elongation of the flexible lifting belt is small, with<2% under working load and<12% under breaking load.
14. The temperature range used is - 40 ℃ - 180 ℃.
15. It can be attached with an anti wear protective sleeve and an anti cutting protective sleeve.
