Precautions for use of stone fixture

Introduction:

The stone fixture used for lifting cylindrical stone is hollow or solid cylinder for some products and semi-finished products. These workpieces are stacked or processed vertically. It is required that the end face and cylindrical surface should not be damaged during loading and unloading, otherwise it will cause defective products and waste products. There are general stone lifting clamps and stone clamps for clamping square workpieces on the market, and cylindrical workpieces can only be lifted by ropes. However, there is a stone fixture specially designed by Longhai Crane, which is specially used for lifting standardized columns or Roman columns. It has proved feasible in practice and solved the problem of bumping the working surface. The stone clamp consists of a ring body, a clamping block, a connecting plate, a pin shaft and a rubber piece

The stone fixture used for lifting cylindrical stone is hollow or solid cylinder for some products and semi-finished products. These workpieces are stacked or processed vertically. It is required that the end face and cylindrical surface should not be damaged during loading and unloading, otherwise it will cause defective products and waste products.

There are general stone lifting clamps and stone clamps for clamping square workpieces on the market, and cylindrical workpieces can only be lifted by ropes. However, there is a specially designed stone fixture, which is specially used to lift the standardized cylinder or Roman cylinder, which has proved feasible in practice and solved the problem of bumping the working surface. The stone clamp is composed of a ring body, a clamping block, a connecting plate, a pin shaft, a rubber sheet and other parts. Four clamping blocks are evenly distributed on the clamp, and the rubber sheet is fixed on the clamping block with countersunk screws. A parallelogram four-bar mechanism is formed by a clamping block, four connecting plates, a torus and four pivot pins to keep the clamping block moving parallel on the working surface.
